Premium Gabion Baskets Versatile Solutions
Gabion Baskets
Gabion baskets that are made of welded wire mesh have application in architecture and residential projects. From common gabions, these baskets are open-topped, with two chambers, which enable separation of infill materials. Built from 4mm diameter wires welded into a 100x50mm mesh grid; these baskets offer outstanding strength as well as load capacity. The strength provided by welded intersections is superior to those of woven wire gabions, providing structural stability in heavy load situations.
Manufacturer Types Gabion Basket for Construction
The manufacturing process of double twisted gabion baskets involves two wire strands being twisted into a resilient and adaptable binding structure. The structural framework of these baskets becomes stronger through double-twisting since it distributes tensile forces equally throughout the fabric. The result supports important applications which require adaptability. The double twisting process:
Gabion Basket Raised Beds: Practical and Elegant
Gabion Basket Benches: Durable Seating Solutions
Gabion Basket Gardens: Creative Landscaping Ideas
Gabion Basket Planters: Modern Design for Plants
Technical Specifications
| Feature | Specification |
|---|---|
| Wire Diameter | 4mm welded steel wire |
| Mesh Size | 100 x 50mm |
| Loading Capacity | 1400 kg/m³ |
| Interconnection | Spiral coils (3.76mm dia, 20mm internal dia, 45mm pitch) |
| Coating Options | Galvanized, Zn-5%Al (Galfan), or PVC-coated |
| Standard Sizes | Customizable as per application |
| Primary Use | Architectural, decorative, and retaining applications |
Feature | Specification |
| Wire Diameter | 4mm welded steel wire |
| Mesh Size | 100 x 50mm |
| Loading Capacity | 1400 kg/m³ |
| Interconnection | Spiral coils (3.76mm dia, 20mm internal dia, 45mm pitch) |
| Coating Options | Galvanized, Zn-5%Al (Galfan), or PVC-coated |
| Standard Sizes | Customizable as per application |
| Primary Use | Architectural, decorative, and retaining applications |
Types of Gabion Basket for Every Need
Welded Gabion Baskets
Industrial machines unite wires and mesh units to create one solid fabric structure during the automated weld fabrication of welded gabion baskets. Welded gabion baskets generate a stable structure with uniformity thus becoming suitable for applications that require precision alongside low maintenance needs. The welding process
Provides Structural Rigidity
Offers Enhanced Stability
Ensures Precision:
Key Features
Exceptional Durability
Long-lasting, high-strength performance is assured through a robust welded mesh design.
Tailored Fits
Adaptable to a wide range of project layouts and installation requirements.
Design Flexibility
Offers flexibility in infill options, enabling more attractive and functional design variations.
Easy Installation & Low Maintenance
Pre-fabricated panels reduce installation complexity and lower maintenance needs over time.
Corrosion Resistance
Offered in Galfan or PVC coatings to improve resistance against corrosion and extend service life.
Applications of Gabion Baskets
Retaining Wall Construction
Erosion Control
Noise Barriers
Gabion Basket Raised Beds
Gabion Basket Benches
Gabion Basket Gardens
Contact Us for your Gabion Basket Needs
Ready to start your project with high-quality gabion boxes? Contact Hi-Tech Gabion today for expert advice and a wide range of options to suit your needs. Fill out the form below or give us a call to discuss your project requirements and receive a customized quote.
