U-Shape Basket
Short Brief
Our
versatile U-shaped gabion baskets come in three different options to meet your
requirements. These baskets are ideal for improving the look of outdoor areas,
ensuring safety, and providing a stylish solution for both homes and
businesses.
Description
Introducing our U-shaped gabion baskets, a
fusion of aesthetics and safety. Featuring two robust posts flanking a spacious
rectangular basket with an open view above, secured by an integrated wire mesh
system. These baskets are ideal for both residential and commercial use, as
they enhance outdoor appeal while addressing safety concerns. We offer various
options to cater to diverse needs, though please note that the inner basket
sizes may vary. The U-shaped gabion basket is constructed using welded wires
made of carbon steel, which has excellent mechanical properties, including good
weldability. The wires are welded at every junction, creating a mesh structure
with a size of 100x50mm. These mesh structures are then joined together using
3mm diameter spiral wire. Additionally, support wires are provided to prevent
the mesh structure from bending due to any force. At Hitech Gabion, we offer
multiple finishing options. By default, we provide a hot-dip galvanized coating
that meets the BS EN 1461 or equivalent standards. These baskets offer a
stylish and secure solution for your outdoor needs.
Features
- Multiple variants are available
- Wire diameter of 4 mm
- Mesh size 100x50mm
- Rust and corrosion resistant
- Better Life
- Galvanized
- Custom finish coating available
- Multiple colors are available
- Stylish design
- 100% Tested
- 100% strong
Application
- Parks
- School
- Hotels
- Public Building
- Offices
- Outdoor spaces
- Residential
- Demarcation
- Sports Center
Technical Specifications
| Material | Carbon steel wire |
| Wire Diameter | 4.00mm |
| Wall Thickness | 100mm |
| Mesh Size | 100x50 mm |
| Spiral coil wire diameter | 3mm |
| Spiral coil inner diameter | 20 mm |
| Spiral Pitch | 45mm |
| Load Capacity | 1400 kg/m3 |
| Assembly Required | Yes |
| Rust proof | Yes |
| Finishing | Galvanized/PVC coating |
| Color | Silve |
Variants Description
|
Variants |
Outer dimensions |
No. Of Partition |
No of Post |
No of Rect Basket |
|
GR210 |
1600 x 200 x1500 mm |
1200 x 200 x 900 | 2 | 1 |
|
GR220 |
2400 x 200 x 1000 mm |
900 x 200 x 600 mm> | 3 | 2 |
|
GR230 |
5700 x 200 x 1000 mm | 900 x 200 x 600 mm> | 6 | 5 |
Finishes
- Products are hot deep Galvanized to BSEN1461 or Equivalent standards.
- Galvanized and Powder coated to BSEN13438 or Equivalent standards.
- Only powder coating to non-standard
- Marine coat Coating for application near salt water
STANDARD COLOURS
- Galvanized
- PVC Ral black 9005
- Custom colors and coating are available
Installation
At Hitech Gabion, we provide premium gabion products tailored to your needs and offer comprehensive support for your project's success. While we don't directly offer installation services, our expert team is available to provide detailed instruction manuals and consultancy to guide you through the installation process. If you require additional installation support, we can connect you with trusted construction vendors. Your satisfaction and project success are our top priorities, and we're committed to helping you achieve outstanding results every step of the way.
